Intel calls the technique of four transfers per cycle Quad Pumping. Many manufacturers publish the frequency of the front-side bus in MHz, but marketing materials often list the theoretical effective signaling rate (which is commonly called megatransfers per second or MT/s). For example, if a motherboard (or processor) has its bus set at 200 MHz and performs 4 transfers per clock cycle, the FSB is rated at 800 MT/s. For example, a 64-bit (8-byte) wide FSB operating at a frequency of 100 MHz that performs 4 transfers per cycle has a bandwidth of 3200 megabytes per second (MB/s): 8 bytes/transfer × 100 MHz × 4 transfers/cycle = 3200 MB/s · The number of transfers per clock cycle depends on the technology used. They are seldom used in embedded systems or similar small computers. The FSB design was a performance improvement over the single system bus designs of the previous decades, but these front-side buses are sometimes referred to as the "system bus". A slow FSB will cause the CPU to spend significant amounts of time waiting for data to arrive from system memory. However, if the computations involving each element are more complex, the processor will spend longer performing these; therefore, the FSB will be able to keep pace because the rate at which the memory is accessed is reduced. Overclocking is the practice of making computer components operate beyond their stock performance levels by manipulating the frequencies at which the component is set to run, and, when necessary, modifying the voltage sent to the component to allow it to operate at these higher frequencies with more stability. Many motherboards allow the user to manually set the clock multiplier and FSB settings by changing jumpers or BIOS settings.

Techware Labs - Reviews - Intel 800 MHz FSB Processors

www.techwarelabs.com

Intel has released its new 800MHz FSB family, but not many mainboards out on the market can support its bandwidth. The 800MHz FSB offers 6.4 GB/s of memory bandwidth. Most motherboards only offer single-channel DDR400 support which only delivers half of the bandwidth of what the 800MHz FSB handles. Many of the latest motherboards out there on the market are now featuring dual-channel DDR400 support. The Intel Springdale and Canterwood are the first of the chipsets to support dual-channel DDR400 for the Intel platform, but other chipset makers like SiS and VIA have chipsets under development to support both DDR400 and the 800MHz FSB bus.

What ever happend to the 800MHz FSB? | [H]ard|Forum

hardforum.com

Now I do have a theory as to why, the 800MHz FSB speed that intle was using was generated on the MOBD probly by the north bridge and so making a faster FSB you needed to be depended on the MOBD chip set, so I'm gussing that when the memory controller and most of the NB chipset got integrated in to the CPU so did the crazy FSB speeds that the CPU needed, keeping the system Bus speed at 100MHz, really now it's just the memory speed that is faster then the Bus speed now as far as I can tell and that talks directly to the CPU so ya I gusse no more need for 800MHz FSB. Anyway this was a fun little think on the past that I grew up with, durring one of the more interesting times in computer hardware history and figured I would ask what happend to the insain FSB of yesteryear. It is the bus that communicates between the System Memory, Memory Controller, and the CCX's, The fclk is the bus that communicates between the CPU and the other SOC components on the die. So basically you can just think of it as an evolution of the traditional FSB. The funny thing about the fclk and uclk is that it communicates way faster than the 800mhz FSB of yesteryear. Bus can also be used to communicate between two or more CPU's and it is these multi-processor systems where all the differences between raw PCI-E and current buses lie (Intel QuickPath Interconnect and AMD Infinity Fabric) BTW. FSB bus on Core 2 was the same FSB bus that was used for all Netburst processors (Pentium 4 and Pentium D) and it had really 1/4 clock of stated clock so your 800MHz was really 200MHz. I would assume that since something like Intel Raptor Lake has 16 lanes of PCI-E 5.0 it also runs Intel QuickPath Interconnect at 32GHz for communicating with Z790 chipset and 16GHz for Z690 chipset. tl;dr Current CPUs have 32000MHz bus speeds 32000MHz >>> 800MHz ps. FSB ran at 64 bits == lanes so difference between maximum data rates in/out CPU is less than difference in clocks.

Frontside Bus - DevX

www.devx.com

And from the motherboard side, Kenji Morita, ex-ASUS chipset designer, recalled the balancing act: “Our job was to tune traces and clock signals so that every component hit the same beat. When DDR400 memory appeared, it was a revelation—we could finally match the 800 MHz bus stride.” · Their memories highlight how the FSB was more than a physical connection. The speed of the FSB determined how quickly a CPU could access main memory and communicate with peripherals. Higher FSB frequencies meant more bandwidth, lower latency, and smoother multitasking. Take Intel’s Pentium 4 line as an example. The jump from a 400 MHz to an 800 MHz bus wasn’t just marketing—it doubled the effective data transfer rate. The FSB may be a relic, yet it’s one worth remembering. It carried the entire PC revolution on its back before the next generation of architectures finally gave it a rest. Why Is Your Device Saying Your Wi-Fi Security Is Weak? ... Comparing Analytics Platforms: Azure vs. AWS ... The DevX Technology Glossary is reviewed by technology experts and writers from our community. Before chiplet architectures and PCIe 5.0, there was a single, unglamorous piece of wiring that defined how fast your computer could think. The front-side bus (FSB) was once the nervous system of every desktop machine.

What does 1333 / 1066 / 800 MHz (FSB) from a motherboard mean? - Quora

www.quora.com

What does FSB: 800(O.C) / 533 / 400 MHz mean? | [H]ard|Forum

hardforum.com

The 3.2Ghz Prescott has a 800 FSB. However, one thing is bugging me... In the Front Side Bus specification, it says: 800(O.C) / 533 / 400 MHz. Which means 800 means Overclocked I presume. So, is it more than just a matter of buying a 3.2 Prescott and dropping it in? Would the computer be "overclocked" and therefore unstable? CPU FSB DDR DIMM Type Memory Frequency *800 Mhz *PC3200 400 Mhz 533 MHz PC2700/PC2100 333/266 Mhz 400 Mhz PC2100 266 Mhz * Overlocked mode * When overclocking to 800Mhz CPU FSB, the system supports only DDR400 (PC3200) DIMMs due to chipset limitation. * The following FSB/DDR ratios are not supported: 400/333, 400/400, 533/400. So what exactly does that overclock information mean? By putting in the 3.2Ghz Prescott, my computer will be automatically "overclocked?" I have a Asus P4P8X SE (Intel 865P) Series. http://www.asus.com/products4.aspx?modelmenu=2&model=183&l1=3&l2=12&l3=32 I currently have a 2.4Ghz Intel Pentium 4, and I want to upgrade to a 3.2Ghz Prescott. The manual says the system supports 800*/533/400MHz front side bus and allows data... The 3.2gb/s is refering to motherboard bandwith between the processor and the chipset/memory. This does not mean that your max upgrade is a 3.2GHz. Thay are 2 different things. If you want get the fastest that they make in that socket and then yes you will need to update your BIOS.
