Some Cisco WLAN access points and VoIP phones supported a proprietary form of PoE many years before there was an IEEE standard for delivering PoE. Cisco's original PoE implementation is not software upgradeable to the IEEE 802.3af standard. Cisco's original PoE equipment is capable of delivering up to 10 W per port. In a passive PoE system, the injector does not communicate with the powered device to negotiate its voltage or wattage requirements but merely supplies power at all times. Most passive systems use the pinout of 802.3af mode B (see § Pinouts) – with DC positive on pins 4 and 5 and negative on 7 and 8. The original PoE standard, IEEE 802.3af-2003, now known as Type 1, provides up to 15.4 W of DC power (minimum 44 V DC and 350 mA) on each port. Both of these standards, 802.3af and 802.3at, were later incorporated into the IEEE 802.3-2012 publication. Power over Ethernet (PoE) describes any of several standards or ad hoc systems that pass electric power along with data on twisted-pair Ethernet cabling. This allows a single cable to provide both a data connection and enough electricity to power networked devices such as wireless access points ...

1 Introduction to PoE and the IEEE802.3af and 802.3at Standards ...

ieee.li

802.3at vs 802.3af: Which PoE Standard to Use

www.cbtnuggets.com

A huge benefit for type 1 devices is the power requirements. Because these have the lowest power requirements, that equates to lower capacity power supplies and circuits to the switches. In other words, it can be more economical. 802.3af devices are compatible with 802.3af and 802.3at switches. It is not a matter of one versus the other. With 802.3at being the newer standard, on the switch side, it is backward compatible. If a port can only negotiate 802.3af due to the end device only supporting that, there will be no issues. The 802.3af standard is also referred to as simply PoE. This is because it is the initial PoE standard. It allows for a maximum of 15.4 watts. Devices that consume at this wattage or less are type 1 devices. Another benefit of this is that at the switch level, it supports type 1 and 2 devices as it is backward compatible with 802.3af.

Power over Ethernet Standards (802.3af, 802.3at, & 802.3bt)

www.nvtphybridge.com

The difference between 802.3af vs. 802.3at (PoE vs. PoE+, respectively) is the amount of power delivered. The 802.3af PoE standard delivers 15.4 Watts to endpoint devices, while the more recent 802.3at PoE standard delivers 25.5 Watts to endpoint devices. Eventually, the industry developed the 802.3bt standard, also known as PoE++. An 802.3bt device delivers 60 Watts of power from the PSE (power sourcing equipment) to ensure 51 Watts to the PD. Industry adoption of 802.3bt was slow as several device manufacturers developed their own technologies during the “wild-wild west” period. As with several networking manufacturers, NVT Phybridge started developing high-wattage PoE technology during the “wild-wild west” period when there was no standard to adhere to. Our goal was to support the highest number of endpoint devices from the six competing methodologies as possible.

Power over Ethernet (PoE) standards and compatibility - NETGEAR ...

kb.netgear.com

PoE (as a general standard, not referring to 802.3af only) lets Ethernet cables supply power to network devices over the existing data connection. If your PoE switch supports IEEE 802.3bt, it can supply power to 802.3bt, 802.3at, and 802.3af powered devices (PDs). Pre-802.3bt: The port supports Class 4 devices that use 4-pair PoE (4PPoE) to receive power higher than 30W but that are not compliant with IEEE 802.3bt. The port also supports the IEEE 802.3at and IEEE 802.3af modes. Pre-802.3bt-lldp: The port supports Class 4 devices that use 4-pair PoE (4PPoE) to receive power higher than 30W (up to the maximum power of 60W) but that are not compliant with IEEE 802.3bt. In this mode, the port allocates the maximum power of 60W to the device. The port also supports the IEEE 802.3at and IEEE 802.3af modes. 802.3bt-type3: The port supports the IEEE 802.3bt Type 3 mode, the IEEE 802.3at mode, and the IEEE 802.3af mode. PoE and PoE standards PoE is a networking feature defined by the IEEE 802.3af (PoE), IEEE 802.3at (PoE+), and IEEE 802.3bt (PoE++) standards.

802.3at vs 802.3af: Exploring the Differences Between PoE Standards

www.fs.com

As network and communication technologies continue to evolve, it is crucial to ensure that equipment is powered efficiently while minimizing the complexity of wiring. PoE has revolutionized how power and data are transmitted by allowing both to travel through a single Ethernet cable. Of the various PoE standards, 802.3at and 802.3af are critical, but understanding the difference between the two can be confusing. However, it's important to note that PoE isn't one-size-fits-all. Different devices have different power requirements, and not all PoE solutions provide the same level of output. This is where PoE standards like IEEE 802.3af and 802.3at come into play. The introduction of the 802.3af PoE standard in 2003 marked the beginning of a new era in network design. It provides the basis for powering devices such as IP cameras, VoIP phones, and WLAN access points directly over network cables. The 802.3af standard can deliver up to 15.4 watts of power per port, with approximately 12.95 watts assured to be available at the device due to power loss over the cable. The primary difference between 802.3at and 802.3af lies in their power delivery capabilities. While the 802.3af is suited for low-power devices, the 802.3at is tailored for gadgets that demand higher power consumption.
