The Advantech AIMB-785 is an active, high-performance industrial ATX motherboard based on the Intel Q170 chipset, designed for 6th/7th Gen Intel processors Advantech Newegg. It is a critical component in the B2B industrial sector, particularly for applications requiring legacy support and high reliability Openpr.

Product Overview & Key Specifications

* Core Architecture: Supports Intel LGA1151 (6th/7th Gen) CPUs with 4x DDR4 slots (up to 64GB) Advantech Itgindia.

* Expansion & Legacy: Features 3x PCI slots, which is a primary driver for its continued demand in industrial automation where legacy interface cards are still in use Advantech Proxis.

* Connectivity: Dual Gigabit LAN, 6x COM ports, and support for triple displays (VGA/DVI-D) Advantech Getuniqcli.

* Industrial Features: Includes a Watchdog Timer, Intel vPro/AMT 11.0 for remote management, and dTPM 2.0 support Newegg Advantech.

Market Trends & Pricing (2026 Context)

* Market Growth: The global industrial motherboard market reached $2.1 billion in 2025 and is projected to grow to $3.2 billion by 2034 (4.68% CAGR), driven by IIoT and Edge AI expansion Researchandmarkets Indexbox.

* Lifecycle Insights: While consumer boards for LGA1151 are obsolete, industrial variants like the AIMB-785 maintain long lifecycles (5–7+ years). Search interest spiked significantly in early 2026, indicating a potential hardware refresh cycle for existing infrastructure Openpr.

* Pricing: Current market prices for the AIMB-785 range from $150 to $799 depending on condition (new vs. refurbished) and supplier Shi Alibaba. Bulk sourcing typically starts at $165–$175 per unit Alibaba.

Sourcing & Supplier Landscape

Key suppliers are primarily located in industrial hubs like Shenzhen and Beijing, offering both original Advantech units and compatible industrial-grade alternatives Alibaba Alibaba.

Detailed pricing, supplier verification, and technical comparisons are provided in the attached files.
