Atx

ATX (Advanced Technology eXtended) Definition

techterms.com

ATX is a motherboard specification that defines the board's physical dimensions, connector placement, I/O ports, and supported power supplies. Intel introduced the ATX specification to replace the previous AT standard for desktop PCs. The ATX specification introduced several significant improvements to motherboard design. It standardized the position of the I/O panel, directly integrating ports into the motherboard. It also moved the CPU and RAM slots to a location where they wouldn't interfere with full-length expansion cards. It sets requirements for compatible power supplies to include a series of connectors to provide power to the motherboard, processor, and expansion cards. It moved the connector for storage devices closer to the location of the drive bays to shorten the length of cables needed. ATX motherboards and cases also provide better airflow through the chassis than older designs. Several variations of the ATX have been introduced since then and are common in desktop computers.

What Does ATX Mean? A Simple Guide for the Tech Curious | SoftBit

www.sybergaming.com

Before ATX, the older "AT" standard made PC building a challenge due to poor airflow and outdated features. In 1995, Intel introduced the Advanced Technology eXtended (ATX) standard, a huge step forward that fixed the old design's problems. ATX stands for Advanced Technology eXtended. So, what does ATX mean? If you're diving into PC building, you've likely seen this term. Simply put, ATX is a foundational standard for personal computer hardware.

ATX - Wikipedia

en.wikipedia.org

↑ "List of computer PSU form factors - SilverStone Technology Co., Ltd". Archived from the original on 2019-02-09. Retrieved 2019-02-09. ↑ SFX-L Computex 2017 roundup - Small Form Factor Network · ↑ Modern Form Factors: EPS, TFX, CFX, LFX, And Flex ATX - Power Supply 101: A Reference Of Specifications ... ↑ Christoph Katzer (2008-09-22). "Debunking Power Supply Myths". AnandTech. p. 3. Archived from the original on June 23, 2011. Retrieved 2014-10-07. ↑ "Cooler Master UCP Product Sheet". While some dual-CPU-socket motherboards have been implemented in ATX, the extra size of EATX makes it the typical form factor for dual-socket systems and for single-socket systems with a large number of memory slots (or more than two memory channels). In 2004, Intel announced the BTX (Balanced Technology eXtended) standard, intended as a replacement for ATX. In September 2009, EVGA Corporation had already released a 13.5 × 10.3 in (343 × 262 mm) "XL-ATX" motherboard as its EVGA X58 Classified 4-Way SLI, which requires an Ultra-ATX sized case to support four "double-slot" graphics cards. Gigabyte Technology launched another XL-ATX motherboard, with model number GA-X58A-UD9 in 2010 measuring at 13.6 × 10.3 in (345 × 262 mm), and GA-X79-UD7 in 2011 measuring at 12.8 × 10.0 in (324 × 253 mm). ATX (Advanced Technology Extended) is a motherboard and power supply form factor and configuration specification developed by Intel. It aimed to improve on previous de facto standards such as the AT design. Originally released in July 1995, it was the first major change in desktop computer ... Portable and notebook computers and some 19-inch rackmount servers have custom motherboards unique to their particular products. Although true E-ATX is 12 × 13 in (305 × 330 mm) most motherboard manufacturers also refer to motherboards with measurements 12 × 10.1 in (305 × 257 mm), 12 × 10.4 in (305 × 264 mm), 12 × 10.5 in (305 × 267 mm) and 12 × 10.7 in (305 × 272 mm) as E-ATX.

What Is ATX (Advanced Technology EXtended)?

www.computerhope.com

Short for advanced technology extended, ATX is a specification used to outline motherboard configuration and dimensions to improve standardization. First released in July 1995 by Intel, ATX has since had many revisions. ATX boards didn't hit the market in force until mid-1996, when they rapidly began replacing Baby-AT boards in new systems. The original ATX motherboard, often called Standard ATX or Full-ATX, is 12" wide x 9.6" deep (305 x 244 mm). Its COM port, LPT port, PS/2, and USB (Universal Serial Bus) are mounted directly on the motherboard. The ATX motherboard includes advanced control facilities, where the BIOS (Basic Input/Output System) program continually checks the CPU (central processing unit) temperature and voltages, the cooling fans RPM (revolutions per minute), etc. The image below is an example of the ATX form factor.

ATX Explained: Motherboard Standard for Desktops

www.electronicshub.org

In the context of motherboards, ATX stands for Advanced Technology eXtended. The process of selecting and assembling components to create a personalized computer system allows individuals to tailor their setups to specific needs, whether it be gaming, content creation, or professional work. One critical component at the heart of every PC build is the motherboard, and among the various form factors available, the ATX (Advanced Technology eXtended) stands out as a popular choice. The ATX form factor was introduced in the mid-1990s as an upgrade to the previous AT (Advanced Technology) form factor. The ATX specification brought several improvements and standardized the design of motherboards. Some key features of ATX motherboards include the following. Size and Dimensions: ATX motherboards typically measure 12 x 9.6 inches (305 x 244 mm). EATX motherboards are generally used in high-end or enthusiast-grade systems that require extensive connectivity and multiple graphics cards. The exact size may vary, but it typically exceeds the dimensions of ATX. Mini-STX: Mini-STX (Mini Socket Technology eXtended) is an even smaller form factor designed for ultra-compact systems.

What is ATX | CORSAIR

www.corsair.com

ATX or Advanced Technology eXtended is part of an Intel-developed platform which follows on from the older AT standard to allow for better design, airflow, standardization of components and ease of installation for the end user while offering backward compatibility with the AT format. ATX is an evolving standard, with the latest revision ATX 3.1 focusing on power and reliability and introducing the updated 12V-2x6 connector, which, while it has proven controversial, it is an evolution which allows for higher power graphics cards it allows for them to have up to 600W through one connector as opposed to needing four PCIE 8-pin cables to achieve the same output. As an example, with a modern ATX motherboard, you can purchase an M.2 drive and be sure that it will fit without issue.
