Centamax 3500

Updated October 6, 2026

Overview

Product sourcing insights & recommendations

20 来源

The Centamax 3500 is a heavy-duty, torsionally flexible rubber-in-shear coupling element designed primarily for diesel engine drives in marine and industrial applications Awelastic Centapowertransmissions. It is widely used to manage torsional vibrations and protect critical drivetrain components from resonance-related failure Centapowertransmissions Rexnord.

1. Product Specifications & Variants

The "3500" refers to its nominal torque capacity, which ranges between 3,200 – 3,800 Nm, with a peak torque capacity reaching 8,500 Nm Awelastic.

* Materials:

* Natural Rubber (NR): Standard black element, suitable for temperatures from –45°C to +80°C Awelastic Centapowertransmissions.

* Silicone (Si): Yellow element, designed for high-heat environments up to +120°C and offering superior oil resistance Awelastic Centapowertransmissions.

* Mounting Types:

* Type SC: Features plain bolt-through holes for standard OEM fitment Awelastic Awelastic.

* Type SCE: Features threaded holes, allowing bolts to tighten directly into the element for alternative mounting configurations Awelastic Awelastic.

2. Key Market Insights & Applications

The market for Centamax 3500 is driven by industries requiring high reliability in vibrating drive systems:

* Marine & Power Gen: Extensive use in boat drives, marine generator sets, and stationary diesel gensets Awelastic Centapowertransmissions.

* Heavy Machinery: Critical for roadbuilding machinery (e.g., asphalt pavers) and drilling rigs, where heat dissipation is vital Centapowertransmissions.

* Trend: Modern low-emission diesel engines operate at higher temperatures, driving a shift toward Silicone and HTC (High Thermal Capacity) designs that offer 2x to 3x better heat dissipation than conventional elements Centapowertransmissions Rexnord.

3. Pricing & Sourcing Landscape

The market offers a wide price spectrum depending on the source and material:

* Original OEM (European Retail): Approx. €1,330 ($1,450) for a standard NR element Awelastic.

* Aftermarket/Interchangeable: European suppliers list high-quality alternatives around €719 ($785) E-Rubber.

* Wholesale/Asian Markets: Regional B2B listings (e.g., IndiaMART) show prices as low as $140 - $200, though these are often aftermarket components Indiamart.

The Centamax 3500 is recognized for its "fail-safe" design, where the rubber element slips under extreme overload (like a short circuit) to protect the engine from catastrophic failure Centapowertransmissions Rexnord.
