Overview

Product sourcing insights & recommendations

45 来源

Insights into Aoyue diaphragms reveal their role as critical spare parts for hot air rework and desoldering stations, though the technology faces increasing pressure from modern turbine-based alternatives.

Product Specifications & Utility

The Aoyue AODP-01 (DP01) diaphragm is the standard replacement part for the internal air compressor in various rework systems Sra-Solder Aoyue3D.

Core Function: Generates airflow for hot air guns and provides vacuum suction for desoldering guns and smoke absorbers Scribd Eevblog.
Compatibility: Fits major models including the 850A++, 852A++, 968A+, and multi-function systems like the 2703A+ Sra-Solder Sra-Solder.
Sourcing Tip: Most pump units require two diaphragms for a full replacement, typically priced around $6.00/piece Wiltec Sra-Shops.

Market Trends & Competitive Insights

While Aoyue remains a respected "budget veteran," the rework station market is shifting toward turbine-driven technologies for professional use Chuxin-Smt Soldermag.

Technology Shift: Diaphragm pumps are noted for pulsatile airflow and higher noise levels, which can displace small SMD components. In contrast, modern turbine stations (e.g., Quick 861DW) offer smoother, high-volume airflow (up to 120L/min) and faster thermal recovery Eevblog Chuxin-Smt.
Brand Position: Aoyue is preferred by hobbyists for its repairability and extensive spare part availability. However, professional repair benches are increasingly adopting high-wattage (1000W+) turbine systems to handle the higher melting points of modern lead-free solder Rcgroups Chuxin-Smt.
Growth Outlook: The hot air SMD rework market is projected to grow at a 9.7% CAGR through 2033, driven by the complexity of multi-layer PCBs and BGA repair requirements Linkedin Insightaceanalytic.

The following file contains B2B sourcing options for rework station diaphragm pumps and related components.

You can further explore these insights with:

Sources & References

45 sources cited · Verified industry data & reports

Replacement Spare parts

Aoyue International Limited

Diaphragm Compressor Aoyue 3017J. Hot Air Gun Barrel with Heat. Diaphragm Pump. Pump Type • Motor Type. Replacement Spare parts

Aoyue Replacement Diaphragm for the Pump

SRA Soldering Products

This diaphragm can be used to replace the pump on the following stations: 850A++, 852A++, 738H, 768, 908, 968968A+ 2702, 2702A+, 2703A+.

Aoyue Replacement Diaphragm for the Pump

SRA Shops

This diaphragm can be used to replace the pump on the following stations: 850A++, 852A++, 738H, 768, 908, 968968A+ 2702, 2702A+, 2703A+.

Aoyue: Advanced Lead Free Repairing System | PDF

Scribd

Advanced LeadFree Repairing System is a reworking equipment that combines the functionality of Hot Air Gun, Soldering Iron, Smoke Absorber, and Desoldering Gun

Aoyue Soldering Equipment & Stations | Best Soldering Iron Kits

Aoyue International Limited

12.3-inch LCD screen – Lowered by 10 millimeters, it enhances handling ability for greater stability on the road. Enhanced cornering, grip & handling

How Pneumatic Diaphragm Pumps Work

Arozone

An air operated double diaphragm pump is a pneumatic pump that uses an air valve that directs compressed air between two sides of the pump, back and forth.
