Digital Earphone Speaker

What is a MEMS speaker? - SoundGuys

www.soundguys.com

While this advance hasn’t received much attention, its importance in the headphone world should be compared to the introduction of SSD technology in computer hard drives. With full-range audio reproduction, compact size, and low power requirements, MEMS speakers will see rapid adoption in audio products like true wireless earphones (TWS), hearing aids, smart glasses, and more. With a response down to 200 Hz, they are intended for consumer products such as tablet computers and TVs. Audio Pixels is one of the pioneers in directly generating sound from a digital audio stream with MEMS devices. Its silicon chip speakers can be stand-alone or cascaded in multiples to achieve the required performance. GraphAudio has developed an electrostatic speaker, but a pure graphene diaphragm is used instead of a metalized polymer film diaphragm. Its initial products are earphones using a graphene diaphragm sandwiched between electrodes. MEMS speaker drivers offer multiple advantages over traditional dynamic moving coil drivers and are ideal for earbud implementations. While manufacturers benefit from easier testing, scalability, and consistency, consumers will experience improved audio quality thanks to some unique characteristics of the new technology. The faster mechanical response — 150 times faster than current technology — means a flat frequency response, better phase response, and lower distortion due to the diaphragm’s material characteristics. From a practical perspective, the major downside to MEMS speakers is that they require a constant bias voltage, like electrostatic headphones. This means that MEMS drivers can’t be used with typical source equipment and need dedicated electronics to drive them. However, MEMS can be powered by integrated circuitry driven by the battery of true wireless (TWS) earbuds, making them an ideal platform to roll out the technology.

r/explainlikeimfive on Reddit: ELI5: What is the mechanism behind ...

www.reddit.com

This is over-simplifying. Digital music is stored as 1's and 0's but that isn't what the speaker is reacting to. It's like the image on your screen right now is controlled by a stream of 1's and 0's but that doesn't mean you can only make your screen all white or all black. If you switch the switch to a speaker on and off (1 and 0) at 1 kHz, you get a 1 kHz tone. With some distinct harmonics, like any noise. A 1 kHz tone made by a simple on-off switch is clearly a 1 kHz tone, but will sound very distinct from 1 kHz tone from a piano, guitar, or someone singing. It sounds electronic, because we associate it with electronics. Really, what that mean is the wave is square. So I wonder how come earphones / headphones doesn't make loud sound externally compared to speakers sound, what's the difference electronic mechanism? These are my earphones.

Headphones - Wikipedia

en.wikipedia.org

The thermoacoustic effect generates sound from the audio frequency Joule heating of the conductor, an effect that is not magnetic and does not vibrate the speaker. In 2013 a carbon nanotube thin-yarn earphone based on the thermoacoustic mechanism was demonstrated by a research group in Tsinghua University. Headphones are also known as earphones or, colloquially, cans. Circumaural (around the ear) and supra-aural (over the ear) headphones use a band over the top of the head to hold the drivers in place. Another type, known as earbuds or earpieces, consists of individual units that plug into the user's ear canal; within that category have been developed cordless air buds using wireless technology. The as-produced CNT thin yarn earphone has a working element called CNT thin yarn thermoacoustic chip. Such a chip is composed of a layer of CNT thin yarn array supported by the silicon wafer, and periodic grooves with certain depth are made on the wafer by micro-fabrication methods to suppress the heat leakage from the CNT yarn to the substrate. Transducer technologies employed much less commonly for headphones include the Heil Air Motion Transformer (AMT); Piezoelectric film; Ribbon planar magnetic; Magnetostriction and Plasma or Ionic. ↑ Telink Staff (19 Aug 2020). "An Introduction to True Wireless Stereo (TWS) Technology". Telink Semiconductor (Press release). Archived from the original on 2024-01-18. ↑ "What Are the Advantages of MEMS Loudspeakers". DigiKey. [The MEMS] speaker itself is built on a PCB substrate. Headphones are a pair of small loudspeaker drivers worn on or around the head over a user's ears. They are electroacoustic transducers, which convert an electrical signal to a corresponding sound. Headphones let a single user listen to an audio source privately, in contrast to a loudspeaker, ...

Digital speaker - Wikipedia

en.wikipedia.org

The widespread use of the term 'digital' with speakers is a marketing ploy intended to claim better suitability with 'digital' source material (e.g., MP3 recordings), or impute 'higher technology' than some other speaker, and perhaps higher price. If pressed, manufacturers may claim the term means the product is 'ready' for input from digital players; this is true of essentially all speaker systems. Digital speakers or digital sound reconstruction (DSR) systems are a form of loudspeaker technology. Not to be confused with modern digital formats and processing, they are yet to be developed as a mature technology, having been experimented with extensively by Bell Labs as far back as the 1920s, but not realized as commercial products. However, electronic filtering is inherently unable to solve this problem with the digital loudspeaker. The speaker elements must operate ultrasonically to avoid introducing (high levels of) audible artifacts, and this means ultrasonic airwaves are inevitable. In recent years, there had been research on the topic of construction of digital loudspeaker arrays in digital sound reconstruction systems using microelectromechanical systems (MEMS). MEMS micro-speaker arrays can be manufactured onto a chip using a CMOS process. A single chip system will have less variations between each subunit compare to a multi-chip system. An Australian-Israel company called Audiopixels recently demonstrated proof of concept in the company's clean room. The audio demonstrates the effectiveness of the MEMS technology after many years of development. The next least significant bit drives a speaker of twice this area, and so on. Other approaches are possible. For example, instead of doubling the area of the next most significant diaphragm segment, it could simply be driven so it stroked twice as far. The digital principle of operation and attendant amplifier efficiency benefits would remain.

New headphone technology features "micro-speakers" made entirely ...

mixmag.net

Until now, speakers have remained one of the few electronic compenents unimproved by silicon technology. xMEMS true solid-state micro speakers are now here to fundamentally change the way people experience sound.” · For more information on xMEMS and the solid-state technology visit its official website. Isaac Muk is Mixmag's Digital Intern, follow him on Twitter On top of changing the speakers for wireless headphones, the company says that the technology can be used to improve technology for hearing aids, in-ear-monitors (IEMs) and emerging technologies such as wearable glasses and sleep buds. Current technology uses coil speakers, which dates back decades, with the silicon build allowing for greater comfort and clarity, more precise audio feedback, as well as a wider sound stage. xMEMS has announced three different solutions of solid-state micro speakers – Cowell, which is now starting mass shipments and the world’s smallest solid-state micro speaker; Montara Plus, which is capable of sound up to 120dB @ 200 Hz; and Skyline DynamicVent, which is designed for earbuds and hearing aids. It follows the trajectory of all-silicon MEMS microphones, which have become the dominant technology in the recording sphere since its introduction in 2007

What Is Digital Signal Processing (DSP) and How Does It Affect Audio?

www.pcmag.com

Sometimes it refers to the process of converting an analog signal to a digital one. Other times it encompasses the gimmicky audio modes in a companion app for true wireless earbuds. In our reviews, the term typically refers to how headphones or speakers adjust an audio signal to ensure ideal sound at all volumes. DSP in wireless headphones and speakers primarily focuses on compressing or limiting the peaks of loud passages to prevent distortion. Imagine the audio signal as a sine wave: If the top of the sine wave crosses a certain threshold, it will distort. In applying dynamic compression, headphones and speakers seek to flatten the peak and keep it from crossing the distortion threshold. Buy some wired headphones or speakers—DSP is generally the norm in wireless audio, while the opposite is true for wired audio. Often, manufacturers that avoid DSP proudly display that fact on their marketing material because they know some people seek that quality specifically. The higher your volume level is when you listen, the more likely it is that peak-limiting DSP will be in play—this is particularly true (or at least, more noticeable) with wireless speakers.
