Dji A2

A2 - A New Standard In Flight Control

www.dji.com

You will need Adobe Reader to read PDF documents. We will stop distributing and updating "A2 Assistant Software v1.9（for Windows & Mac）" on May 15, 2018, including adaptations to the new version of the operating system. After May 15, 2018, the software is still available for download.

DJI has released A2, the new high-end multi-rotor flight controller

www.dji.com

Combined with abundant output interfaces, flexible configuration, it makes the flight controller competent for complex control and airborne equipment operation; the new dual CAN-Bus design greatly improves the data throughput and stability of the system. Based on the technology and design philosophy of DJI’s Ace series of high-performance controllers, the A2 offers you a brand new flight experience. The A2 adopts a full metal case design and utilizes high quality components precisely calibrated with temperature compensation in all gyros and sensors, industry renowned flight algorithm in flight control and UAV field. Sound alarm function for the flight control system; Remote gain value adjustmentsupported by setting a knobon the Transmitter; Support DJI series products, including Z15 gimbal, iOSD Mark II, 2.4G DATA LINK and iPAD Ground Station; Notices： Power supply from the USB cable connected to the PC is available, when connect the A2 Flight Control System to the PC to configure parameters, no extra power supply is required. It opens an unprecedented era of precise positioning and perfect flight control in harsh environments for flight control systems. Its high performance antenna, low noise anti-interference front-end RF design, accurate position and speed calculating comprehensive technological breakthroughs, all these make the positioning performance of the GPS Pro near perfection; With higher accuracy performance, larger measuring range, and a unique damping design and calibration algorithm, the IMU is able to provide stable output even in high vibration and large movement environments.

A2 - Specs | DJI

www.dji.com

DJI A2 Multi-Rotor stabilization controller is impossibly precise, a new standard in flight control.

©2013-2014 DJI Innovations. All Rights Reserved. 1 A2 Flight Control ...

download.dji-innovations.com

Should be connected to the CAN1 port of the Controller Unit, and be mounted according to · the required location and orientation. The IMU has been calibrated before delivery, it should be used under the · specified temperature; otherwise the temperature may have an effect on the IMU performance. ... Please mount the IMU as one of the following options. Configure in the A2 Assistant software ->Basic ->Mount -> The DJI A2 Multi-Rotor stabilization controller is a complete flight system for various multi-rotor platforms for · commercial and industrial aerial photography. Based on the technology and design philosophy of DJI’s Ace · series of high-performance controllers, the A2 offers you a brand new flight experience. A2 features includes: (1) Integrated with high-precision sensor components and a high-performance GPS Receiver. (2) Utilizes high quality components precisely calibrated with temperature compensation in all gyros and · sensors, industry renowned flight algorithm in autopilot and UAV field. (3) Designed with built-in vibration absorption, no extra mount frame or vibration absorption pad is required. (4) Provide high precision control and high performance handling experience.

DJI A2 Flight Controller with GPS/Compass

www.getfpv.com

The DJI A2 Flight Controller is the most advanced multirotor stabilization controller on the market, and it ensures total ease of flight, reliability, and stability in any situation. A2 has a POI function: Point of Interest. When the GPS signal is good, users can record the current position of the aircraft as a point of interest by a preset switch on the remote controller. The aircraft can achieve a circling flight around the point of interest with the nose pointing at the POI in an area of 5 meters to 500 meters radius, when the roll command is given. If the multirotor and its controller disconnects during flight, the system’s failsafe protection will come to the rescue and if the signal is good enough, the multirotor will return to home and land automatically. This function means that when the aircraft is in attitude or GPS attitude mode, and one of the motors stops, the aircraft will retain good attitude and rotate around the frame arm with the stopped motor. In this condition, the aircraft is still under control and returns home safely and highly reduces the risk of a crash.

DJI A2 Multi-Rotor Flight Control System w/iOSD MARK II Combo

hobbyking.com

Inherited from the technology of DJI’s Wookong series controller, the A2 offers you a brand new flight experience with a new design philosophy. Superseding the Wookong family, the A2 sticks closely to DJI’s tradition of wowing customers with high specs, but it also innovates dramatically in a couple of key areas, which DJI hopes will give it an edge over the competition: A2 Features: • Precise Position Hold in Extreme Environments • High Accuracy and Anti-vibration Dampening Characteristics • Built-in 2.4ghz DESST Receiver • Flexible extension capability • Remote Parameter Adjustment Enabled • Upgraded Power Management Unit (PMU) • Dual CAN-Bus System • Advanced Friendly Features • DJI A2 Multi-rotor Flight Controller It has a strong adaptability and can work normally between -20?~60?. iOSD MARK II Features: • Highly integrated, beautiful and practical, compact size • Supports DJI professional autopilot system • Real-time accurate flight data & video signal superposition • Supports dual video source input, switchable during flight • Remote video link channels in real-time switch • Flight Log Function • Free Firmware Upgrades Online • Built-in BEC module, supports 3S-6S LiPoly • User-friendly Assistant Software For more in-depth specs and details, please visit DJI's iOSD MARK II product page by clicking here. Included: DJI A2 Multi-Rotor Flight Control System DJI iOSD MARK II DJI A2 Multi-Rotor Flight Control System w/iOSD MARK II Combo
