TLF15516B FBT Replacement Guide for Samsung/LG CRT TVs

The TLF15516B is a Flyback Transformer (FBT), also known as a Line Output Transformer (LOPT), primarily used as a critical repair component for 14-inch to 21-inch CRT televisions Findcomponents Scribd. It was widely utilized in Samsung (specifically the KS1A, KS9A, and S15A chassis) and GoldStar/LG televisions Scribd.

Technical Specifications & Application

* Function: Generates the high voltage (EHT, typically 25kV–27kV) required for the CRT and provide auxiliary voltages for video output (RGB), focus, screen, and heater circuits Scribd.

* Pinout Profile: A 10-pin configuration featuring a B+ input (110V–130V), Collector (HOT) connection, and dual low-voltage supplies (±14V/16.5V) Scribd.

* Equivalents: The most common high-quality replacement is the HR 8333 (HR Diemen) Scribd. Other crosses include Samsung AA26-20003B and Diemen 154-177B Scribd.

Market Trends & Insights

* Supply Status: As a legacy CRT component, the TLF15516B is no longer in mass production by original manufacturers like Panasonic/Matsushita. The current market is dominated by aftermarket replacements from specialized electronics manufacturers in China (e.g., Sichuan Junhengtai, Hangzhou Smart Technology) .

* Component Market Dynamics: The broader electronic components market is shifting toward automotive electrification and 5G infrastructure, with active components projected to reach a $0.91 trillion to $1.19 trillion value by 2031–2033 Fairfieldmarketresearch Mordorintelligence.

* Niche Demand: While the CRT market has largely been replaced by LCD/LED technology, a steady "long-tail" demand remains in developing markets and the retro-gaming community, where CRT repair parts like the TLF15516B are still sought after Verifiedmarketreports Sunmafiber.

I have compiled a list of potential B2B suppliers and similar flyback transformers currently available in the repair market for your reference.
