Heds 9000 A00

The HEDS-9000#A00 is an active, high-performance optical incremental encoder module manufactured by Broadcom (formerly Avago). It is widely utilized in industrial motion control, factory automation, and high-volume office equipment like printers and plotters MouserMouser.

Key Product Insights

• Technical Performance: This module provides 500 CPR resolution with a 2-channel quadrature output. It is highly valued for its misalignment tolerance, featuring a collimated LED source and a unique photodetector array that simplifies assembly by eliminating the need for signal adjustment Mouser.
• Operating Parameters: It operates on a 5V supply, consumes typically 17 mA, and is rated for a wide temperature range of -40°C to 100°C DigikeyMouser.
• System Integration: It is designed for use with the HEDS-6100 series codewheel (optical radius of 23.36 mm) and features a standard 5-pin vertical PCB/chassis mount header Win-SourceMouser.

Market Trends & Availability

• Lead Times & Demand: Current market data from major distributors like Mouser and DigiKey indicates extended lead times of 16 to 19 weeks, reflecting steady industrial demand and moderate manufacturing queues NewarkMouser.
• Pricing Strategy: Single-unit retail prices range between $36.50 and $37.30. Wholesale opportunities are available through B2B channels, with related HEDS-9100 series modules listed as low as $7.50–$15.00 for bulk orders DigikeyMouser.
• Supplier Landscape: While exact "A00" stock is concentrated among major electronic distributors, several B2B suppliers in Shenzhen, China, offer the broader HEDS-9000 series with OEM and customization capabilities for large-scale integration .

Detailed product listings and specialized supplier profiles are available in the files below.
