Ensures correct assembly and provides versatility Ten polarization options and colored headers are available for either end of the cable assembly. Delivers robust reliability with a fully protected shield case The right-angle header includes a rear-side closed shield to enhance mechanical ruggedness and EMI protection. ... The high-speed performance and robust reliability of the HSAutoLink Interconnect System makes it ideal for a wide range of applications outside the automotive industry. Mechanical keying, color-coded headers and versatile exit-angle options simplify assembly operations and reduce costly errors, while full-length cable shielding enhances signal integrity and system performance. The HSAutoLink system offers exceptional versatility through mix-and-match compatibility with HSAutoLink II and HSAutoLink C connectors. Discover how a variety of features and the availability of multiple tooled HSAutoLink configurations can help shorten lead times and enhance design flexibility without sacrificing quality. ... Camera to controller Connected vehicle services Controller to display Infotainment Diagnostic systems Navigation systems ... This is not a definitive list of applications for this product. Delivering reliable and efficient connectivity for vehicle applications, the HSAutoLink Interconnect System offers a proven, USCAR30-compliant point-to-point connection solution. The system utilizes superior signal integrity and electromagnetic interference (EMI) shielding to support essential protocols such as USB 2.0, LVDS, A2B and 100Base-T1 Ethernet.

HSAutoLink II Interconnect System | Molex

www.molex.com

Explore the HSAutoLink II connectors and cable assemblies, providing versatile and robust differential-pair connectivity solutions for transportation applications. Featuring customizable high-speed pin configurations, these systems support USB, Ethernet, LVDS and more, with data rates up to 13.5Gbps. The HSAutoLink II Interconnect System supports multiple high-speed protocols within the same connector, including USB 3.0, LVDS and Ethernet. Multiple high-speed pin configurations and cable exit options optimize PCB space and simplify design work. The proven low-force helix (LFH) terminal, fully protected shield case and robust sealing options rated up to IP69K help ensure reliable high-speed data transfer performance even in challenging automotive conditions. Reduces PCB footprint with customizable pinout configurations With multiple high-speed pinout configurations and cable exit options, the HSAutoLink II System saves space on the PCB compared with alternative products. HSAutoLink II connectors and cable assemblies provide a versatile, robust and high-speed differential-pair connectivity solution for transportation applications. With a variety of customizable pin configurations, the HSAutoLink II System helps designers address demands for more bandwidth and higher reliability.

HSAutoLink C Interconnect System | Molex

www.molex.com

The HSAutoLink C Interconnect System incorporates 24 pins and multiple cable routing options into a single compact connector housing, providing a high-density design that optimizes space and functionality. The design delivers high-speed data rates up to 40Gbps and 240W of power to support multiple protocols, including USB, LVDS and Ethernet. The HSAutoLink C connector is a USCAR Type C interface and offers both sealed and unsealed options. Connector position assurance (CPA) helps ensure reliable operation in harsh automotive conditions subject to moisture and vibration, while multiple cable exits and strain relief angles help simplify module design. The HSAutoLink C system offers multiple cable exit options including single-, dual- and triple-exit cables and multiple strain relief angles (e.g. straight, 90° down and 45° up) to enhance design flexibility and space optimization. Enhances design flexibility Multiple cable configurations, header configurations and pinout options simplify design work and allow the connector to meet specific PCB design requirements. ... The HSAutoLink C Interconnect System utilizes a Molex-designed Type C interface to deliver data rates up to 40Gbps and as much as 240W of power.

HSAutolink Interconnect Systems Reference Guide

www.ttiasia.com

Full-length cable shielding provides superior signal performance and reduced Electro-Magnetic · Interference (EMI) HSAUTOLINK II · Product · Description · Headers · Manufactured from high-temperature plastic material that is compatible with lead-free through-hold reflow · process (Pin-in-Paste) or lead-free selective wave soldering process · Rear (soldering) side of right-angle headers features closed shield case providing robustness and guarantees · Flexible, expandable product family with data rates up to 5 Gbps allowing for combined links and supporting · multiple protocols in the same connector (USB 2.0, USB 3.0, LVDS, Ethernet AVB, HDMI*, MicroCross DVI, ... Compatible with shielded twisted-pair (STP) or jacketed unshielded twisted pair (JUTP) cable construction Full turn-key testing and product validation provided including complete electrical, mechancial, environmental, EMI,

HSAutolink Interconnect Systems Reference Guide

www.tti.com

Full-length cable shielding provides superior signal performance and reduced Electro-Magnetic · Interference (EMI) HSAUTOLINK II · Product · Description · Headers · Manufactured from high-temperature plastic material that is compatible with lead-free through-hold reflow · process (Pin-in-Paste) or lead-free selective wave soldering process · Rear (soldering) side of right-angle headers features closed shield case providing robustness and guarantees · Flexible, expandable product family with data rates up to 5 Gbps allowing for combined links and supporting · multiple protocols in the same connector (USB 2.0, USB 3.0, LVDS, Ethernet AVB, HDMI*, MicroCross DVI, ... Compatible with shielded twisted-pair (STP) or jacketed unshielded twisted pair (JUTP) cable construction Full turn-key testing and product validation provided including complete electrical, mechancial, environmental, EMI,

HSAutoLink II Interconnect System - Molex | DigiKey

www.digikey.com

Please see product page, cart, and checkout for actual ship speed. ... The robust HSAutoLink II interconnect system from Molex delivers data rates up to 5 Gbps, supporting high-speed media protocols including USB 3.1 (5 Gb/s data rate), to meet increasing bandwidth requirements for advanced in-vehicle infotainment, telematics, and camera devices. HSAutoLink Interconnect System The compact design of the Molex HSAutoLink interconnect system ensures robust performance and seamless integration for infotainment and navigation systems. USB Connectors Molex offers a wide variety of A, B, and C USB 2.0-, 3.0, and 3.1 connectors and cable assemblies to help support power connection and data exchange. HDMI Connectors and Cable Assemblies Molex’s HDMI connectors and cable assemblies provide uncompressed digital connections from any audio/video source to an audio/video monitor over a single cable. Average Time to Ship 1-3 Days. Please see product page, cart, and checkout for actual ship speed.
