M50560 Datasheet

Updated October 6, 2026

Overview

Product sourcing insights & recommendations

27 来源

The M50560 is a legacy CMOS integrated circuit primarily manufactured by Mitsubishi Electric, designed for infrared (IR) remote control transmission. It is commonly found in older consumer electronics such as Hi-Fi systems, TVs, and air conditioners Cselettronica.

1. Datasheet Highlights & Key Specs

* Function: An infrared transmitter IC that supports a 4 x 8 key matrix (32 keys) Cselettronica.

* Operating Voltage: Typically 2.0V to 4.0V, optimized for standard 3V battery operation Cselettronica.

* Transmission Format: Utilizes a 16-bit code structure consisting of an 8-bit custom system address and 8-bit data/commands Cselettronica.

* Oscillator: Requires an external 455 kHz ceramic resonator Cselettronica.

* Compatible Alternatives: The PT2560 from Princeton Technology is a functional alternative, though it requires specific pin-out considerations (Pin 3 is "No Connection" on PT2560 vs. capacitor-connected on M50560) Cselettronica.

2. Market Trends & Insights (2026)

The market for the M50560 has shifted from mass production to maintenance and legacy support.

* Supply Dynamics: The IC is no longer in active high-volume production by Mitsubishi. Current availability is driven by Independent Electronic Component Distributors who hold "New Old Stock" (NOS) Censtry Utsource.

* Availability:

* Censtry: Holds approximately 1,788 pieces of the M50560-473GP variant Censtry.

* UTSource: Lists the M50560-002P variant for immediate purchase with an MOQ of 1 Utsource.

* Pricing Insights: Retail prices for single units range between $3.98 and $4.43 USD Utsource. Bulk pricing for the 1,700+ units at Censtry is available upon request (RFQ), reflecting typical market behavior for low-supply legacy parts Censtry.

* Legacy Shift: In modern design, this IC has been largely replaced by programmable microcontrollers (MCUs) with built-in IR modules, which offer higher flexibility at lower costs for new manufacturing Datasheetarchive Cselettronica.

3. Application Summary

Category	Common Uses
Audio/Video	CD players, amplifiers, and VCRs Cselettronica
Home Climate	Air conditioner remote handsets Cselettronica
Repair Market	Restoration of vintage electronics and legacy IR remotes Censtry Cselettronica
