PS21563-P IPM Datasheet & Supplier Guide

The PS21563-P is a Mitsubishi/Powerex Intelligent Power Module (IPM) from the Mini DIPIPM™ (Version 3) series, primarily designed for low-loss 3-phase inverter applications such as home appliances (air conditioners, washing machines) and small industrial motor drives Digikey Ic-Components.

Product Specifications & Features

The module integrates IGBTs, drive circuits, and protection logic into a compact 35-pin PowerDIP package Digikey Ovaga.

* Electrical Ratings: 600V voltage and 10A current Win-Source.

* Protection: Includes control supply under-voltage (UV) and short-circuit (SC) protection Ineltron Scribd.

* Compatibility: The module uses low-level active logic compatible with 3.3V/5V MCU interfaces Scribd.

Market Trends & Insights

* Market Growth: The global Intelligent Power Module market is projected to reach approximately $2.6 billion by 2026, growing at a CAGR of 7.75% to 12.2% through 2030-2033 Yahoo Coherentmarketinsights.

* Demand Drivers: Growth is fueled by the rising adoption of energy-efficient home appliances and the expansion of industrial automation Yahoo Linkedin.

* Supply Dynamics: While the PS21563-P remains a staple for repairs and legacy designs, newer versions like the PS21963 series are increasingly preferred in modern designs for their enhanced efficiency and smaller footprints Alibaba.

* Replacement Caution: Note that the PS21563-P is not pin-compatible with the PS21564-SP due to different pin counts (35-pin vs. 37-pin) Ovaga.

Detailed product listings and supplier availability data for these modules are consolidated in the file below.
