Nvidia G86 630 A2

Updated July 3, 2026

Overview

Product sourcing insights & recommendations

26 来源

The NVIDIA G86-630-A2 is a legacy mobile graphics chipset, commonly known as the GeForce 8400M GS Parts4Laptops Parts4Laptops. Originally released in April 2007, it was a staple in mid-range "thin and light" laptops from brands like Dell, HP, and Acer Techpowerup Parts4Laptops.

Product Overview & Technical Specs

Built on the Tesla architecture using an 80nm process, this BGA-533 chip features 16 unified shaders and was typically paired with 256MB of GDDR2/GDDR3 memory Parts4Laptops Techpowerup.

* Performance: It offers a core clock of 400 MHz and supports DirectX 11.1 (Feature Level 10_0) Techpowerup Parts4Laptops.

* Legacy Context: The G86 series is historically known for the "NVIDIA Bump Underfill" issue, which caused thermal cycling failures in early 2007–2008 batches Parts4Laptops. Replacement chips labeled "New 2012" or "09+" date codes often feature improved materials to mitigate these risks Seekic Parts4Laptops.

Market Trends & Insights (2026)

The market for the G86-630-A2 is now almost exclusively driven by legacy repair and industrial maintenance.

* Steady Demand in Repair: While obsolete for modern gaming, there is a consistent niche demand for "New Old Stock" (NOS) chips to repair specialized or legacy laptop systems that are still in industrial or personal use Ebay.

* Price & Availability: Current B2B listings show units available for as low as $0.99 to $1.00 USD in bulk, though retail prices for verified "New" stock can range from $15.00 to $35.00 USD depending on the source Seekic Alibaba Techstudiomumbai.

* Geographic Focus: A significant portion of the global supply is concentrated in Shenzhen, China, where vendors specialize in vintage IC components and refurbished chips Seekic Ebay.

For detailed sourcing options, please refer to the attached product list which includes pricing, MOQ, and supplier details.

Would you like to analyze the price trends of the G86-630-A2 over the past few years?
