Pickit 2

PICKIT 2 DEVELOPMENT PROGRAMMER/DEBUGGER

www.microchip.com

Not recommended for new designs and does not support new devices. To be discontinued. Please see the PICkit 3: PG164130. This item is not available for the academic discount. The PICkit 2 and PICkit 3 are not production programmers. The PICkit™ 2 Development Programmer/Debugger (PG164120) is a low-cost development tool with an easy to use interface for programming and debugging Microchip’s Flash families of microcontrollers. The full featured Windows® programming interface supports baseline (PIC10F, PIC12F5xx, PIC16F5xx), midrange (PIC12F6xx, PIC16F), PIC18F, PIC24, dsPIC30, dsPIC33, and PIC32 families of 8-bit, 16-bit, and 32-bit microcontrollers, and many Microchip Serial EEPROM products. With Microchip’s powerful MPLAB Integrated Development Environment (IDE) the PICkit™ 2 enables in-circuit debugging on most PIC® microcontrollers. In-Circuit-Debugging runs, halts and single steps the program while the PIC microcontroller is embedded in the application.

PICkit - Wikipedia

en.wikipedia.org

The PICkit 2 was introduced in May 2005 to replace the PICkit 1. The PICkit 2 has a separate programmer/debugger unit which plugs into the board carrying the chip to be programmed, whereas the PICkit 1 is a single unit. This makes it possible to use the programmer with a custom circuit board via an in-circuit serial programming (ICSP) header. This feature is not intended for so-called "production" programming, however. The PICkit 2 firmware allows the user to program and debug most of the 8 and 16-bit PICmicro and dsPIC members of the Microchip product line. The PICkit 2 is open to the public, including its hardware schematic, firmware source code (in C language), and application programs (in C# language). The PICkit Basic is designed for simple development and is not intended for use in a production environment. Similar to the PICkit 5, the PICkit Basic is based on a 32-bit SAM E70 Arm Cortex-M7 at 300 MHz and features an 8-pin Single In-Line connector, USB-C interface operating at USB 2.0 speeds, hardware and software breakpoints, real-time debugging at full target speed, emergency recovery button for boot firmware recovery. A new command-line application that supports both PICkit2 and PICkit3 devices. New programming protocol support for new classes of Microchip's 8-bit PIC microcontrollers. Updated and managed 8-bit microcontroller database, to keep the software current with future microcontroller products. Improved user interface. Improved reliability (bug fixes). Improved help and users PDFs. Software is compatible with existing integrated development environment (IDE) software. Supports low-voltage (2v to 6v) programming (LVP), and high-voltage (9v to 12v) programming (HVP) With this modification, the PICkit 2 supports eight times as much memory as the PICkit 3. This enhancement has been contributed by Au Group Electronics and the PICkit 2 firmware is also reported to be submitted to the Microchip PICkit 2 team in the middle of March 2009.

Kanda - PICKIT 2 Programmer and Emulator with MPLAB software

www.kanda.com

Programmers Emulators Chips and Modules Bluetooth Wireless Product Index Manufacturer Index Special Offers ... For replacement, see PICKIT3 Microchip PICkit 2 programmer and emulator for PIC microcontrollers. The unit runs from MPLAB IDE (MPLAB 8 or X versions) or can be run from separate programming software. The PICKit2 supports all released PIC microcontrollers as a programmer. As a debugger, it can run on all devices with on-chip debug, which is the majority of all PICs. The PICKit 2 is supported by all MPLAB versions, including the latest MPLAB X. It can run as a debugger in assembler or with C code from all PIC compilers including Hi-tech and Microchip XC compilers. ... Product News Special Offers Sena Products A-Z Product Index Manufacturer Index Software Downloads Contact Kanda: PICKIT 2 Programmer and Emulator with MPLAB software for programming and debugging PIC microcontrollers Kanda supply our AVR programmer range, PIC programmer range, Universal programmers, AVR board, CANUSB and all our other products to electronic engineers worldwide. We have happy customers for our AVR, PIC and Universal Programmer and other electronic tools in UK and Ireland, Norway, Denmark, Sweden, Finland and other European countries like Netherlands, Switzerland, Austria, Germany, France, Belgium, Spain and Italy. Outside of Europe, Kanda is strong in USA, Canada, Brazil and other South American countries. Kanda also supply our products further afield in Russia, Australia, Singapore, South Korea, Japan, New Zealand and India.

Review of Microchip PICkit 2 « RAYSHOBBY.NET

rayshobby.net

But it’s time to try something new in a new year 🙂 PICs offer several nice appeals including their product variety and functionality (e.g. support for USB, Ethernet, touch sensing etc.) and they have very competitive pricing. I know there are tons of debates about AVRs vs. PICs online. For now I am going to put them aside and make my own comparisons later after I get a good grip of both. PICkit 2 is a very popular tool for programming and debugging Microchip’s PIC microcontrollers. For AVRs, the comparable product would be quite a bit more expensive. So overall, I am really glad to find out that this small and inexpensive programmer packs a lot of nice features in it. Next I will try to write my first PIC program. There are basically two pieces of software to install: the MPLAB (version 8.6) which is the programming IDE, and the PICkit 2 standalone program (version 2.61). So far my first experience with the PICkit 2 programmer has been very positive. It’s small, inexpensive, feature-rich, and relatively easy to use. I highly recommend it. In fact, if you are planning to learn PIC programming, I suggest getting this kit soon. Why? I’ve read from online websites that Microchip is discontinuing this product in favor of the newer PICkit 3, which is pricier and has actually received some negative comments (search for David Jones EEVblog PICkit 3 and you will find out). Product page of PICkit 2 on Newark.com (Newark is the trade name of Farnell in the US, or Element14 in Asia Pacific).

Review of Microchip PICkit 2 | OpenThings

openthings.io

But it’s time to try something new in a new year 🙂 PICs offer several nice appeals including their product variety and functionality (e.g. support for USB, Ethernet, touch sensing etc.) and they have very competitive pricing. I know there are tons of debates about AVRs vs. PICs online. For now I am going to put them aside and make my own comparisons later after I get a good grip of both. PICkit 2 is a very popular tool for programming and debugging Microchip’s PIC microcontrollers. For AVRs, the comparable product would be quite a bit more expensive. So overall, I am really glad to find out that this small and inexpensive programmer packs a lot of nice features in it. Next I will try to write my first PIC program. There are basically two pieces of software to install: the MPLAB (version 8.6) which is the programming IDE, and the PICkit 2 standalone program (version 2.61). So far my first experience with the PICkit 2 programmer has been very positive. It’s small, inexpensive, feature-rich, and relatively easy to use. I highly recommend it. In fact, if you are planning to learn PIC programming, I suggest getting this kit soon. Why? I’ve read from online websites that Microchip is discontinuing this product in favor of the newer PICkit 3, which is pricier and has actually received some negative comments (search for David Jones EEVblog PICkit 3 and you will find out). Product page of PICkit 2 on Newark.com (Newark is the trade name of Farnell in the US, or Element14 in Asia Pacific).

PICKIT™ 2 STARTER KIT

www.microchip.com

Please see the PICkit 3 Starter Kit: DV164130. The PICkit 2 Starter Kit contains a PICkit 2 Microcontroller Programmer and a PICkit 2 Low Pin Count Demo Board containing a PIC16F690 PDIP for getting started with programming baseline and midrange flash microcontrollers. PICkit 2 takes advantage of Microchips Full-Speed USB device, thereby significantly speeding up development programming. The PICkit 2 Low Pin Count Demo Board supports 8-, 14-, and 20-pin PICmicros. In addition to the PIC16F690, the board comes with 4 LEDs, a pushbutton, and a pot.
