1. The CS amplifiers has infinite input impedance (draws no current at DC), and a moderately high output resistance (easier to match for maximum · power transfer), and a high voltage gain (a desirable feature of an ampli- fier). 2. Reducing RD reduces the output resistance of a CS amplifier, but unfortu- nately, the voltage gain is also reduced. implying high power consumption from the signal source. 3.1 · Summary of the CG Amplifier · 1. The CG amplifier has a low input resistance 1/gm. This is undesirable as · it will draw large current when driven by a voltage input. 2. The voltage gain of the CG amplifier can be made similar in magnitude · to that of the CS amplifier if RD||RL can be made large compared to · Figure 1(a) shows the small-signal model for the common-source amplifier. Figure 1: (a) Small-signal model for a common-source amplifier.
