Pq5050 Core
Overview
Product sourcing insights & recommendations
The PQ5050 core is a high-performance Mn-Zn soft ferrite magnetic core designed for high-power density applications. Its geometry is optimized for an efficient ratio of volume to winding area, making it a staple in modern Switched-Mode Power Supplies (SMPS) and LLC resonant converters CosmoferritesMag-Inc.
Product Specifications & Design
* Dimensions: It features a round center post that reduces copper losses by minimizing the turn length compared to traditional E-cores Tdk.
* Key Parameters: A typical set weighs ~190g with an effective magnetic cross-section ($A_e$) of 332 mm² and an effective path length ($l_e$) of 113 mm TdkChinadmegc.
* Materials: Commonly available in N95 and N97 grades, which offer low core loss at frequencies up to 500 kHz, particularly optimized for temperatures between 60°C and 100°C TdkPassive-Components.
Market Trends & Insights
The global ferrite core market is projected to grow from $4.5B (2023) to $7.5B by 2033, reflecting a 5.2% CAGR Market.
* EV & Renewable Growth: Demand is heavily driven by the electrification of vehicles and solar inverter adoption, which require the high-efficiency power conversion provided by PQ-series cores SkyquesttBusinessresearchinsights.
* Miniaturization: As electronics shrink, the PQ5050's ability to provide maximum power output with minimal board footprint makes it highly competitive against larger E-core alternatives Cosmoferrites.
* Pricing: B2B market rates for Mn-Zn PQ5050 cores generally range from $1.00 to $2.00 per pair, with high-volume MOQ orders (1,000+) seeing prices drop toward the lower end of that scale AlibabaAlibabaAlibaba.
Sourcing Landscape
Production is concentrated in the Asia-Pacific region (>42% market share), particularly in Chinese manufacturing hubs like Jiangsu and Zhejiang MarketresearchMarket. Suppliers such as Xuyi Ouge Electronic and Huzhou Careful Magnetism dominate the export market, offering specialized customization for magnetic permeability and gapped core configurations AlibabaAlibaba.
