SSP10N80 Datasheet & Sourcing Guide

The SSP10N80 is an N-Channel Power MOSFET characterized by its 800V drain-source voltage and 10A continuous drain current Unisonic Scribd. It is primarily manufactured using advanced planar stripe DMOS technology and is commonly used in high-efficiency Switch Mode Power Supplies (SMPS), DC-to-DC converters, and PWM motor controls Unisonic Pipsemi.

Technical Specifications Overview

The device is produced by several major semiconductor manufacturers including Unisonic Technologies (UTC), Nell Semiconductor, and PIPsemi Unisonic Scribd Pipsemi.

Parameter	Specification (Typical/Max)	Source
Drain-Source Voltage ($V_{DSS}$)	800V	Unisonic Scribd
Continuous Drain Current ($I_D$)	10A	Scribd Pipsemi
Static On-Resistance ($R_{DS(ON)}$)	1.1 $\Omega$ to 1.15 $\Omega$	Unisonic Pipsemi
Gate-Source Voltage ($V_{GS}$)	$\pm$30V	Unisonic Scribd
Gate-Source Threshold ($V_{GS(TH)}$)	2.0V to 5.0V	Unisonic Pipsemi
Total Gate Charge ($Q_G$)	58nC to 65nC	Unisonic Pipsemi

Market Trends & Availability

The global Power MOSFET market is experiencing steady growth, with a projected value reaching between US$14.5 billion to US$15.03 billion by 2031-2032, driven by a compound annual growth rate (CAGR) of approximately 6.6% to 7.12% Transparencymarketresearch Verifiedmarketresearch Straitsresearch.

* Regional Dominance: The Asia-Pacific region, particularly Shenzhen, China, serves as a major hub for the supply and distribution of the 10N80 series .

* Pricing Insights: Bulk pricing for original and compatible 10N80 parts currently ranges from US$0.01 to US$5.65 depending on the specific package (TO-220, TO-3P, TO-252) and order volume .

* Inventory Status: High-voltage MOSFETs like the SSP10N80 are widely available "in stock" from various electronics trading companies in China, reflecting a stable supply chain for standard power applications .
