Overview

Product sourcing insights & recommendations

23 来源

The T315XW02 series refers to a 31.5-inch WXGA (1366 x 768) TFT-LCD panel manufactured by AU Optronics (AUO). These panels were widely used in 32" LCD TVs and industrial displays during the late 2000s and early 2010s.

Technical Profile

The series includes multiple versions (e.g., V9, VL, VC, VS), all sharing core structural characteristics Twscreen Panelook:

* Resolution: 1366 × 768 (WXGA) with a 16:9 aspect ratio.

* Display Quality: Offers high brightness (450–500 cd/m²) and wide viewing angles of 178° (89/89/89/89) Twscreen Scribd.

* Backlighting: Uses aging CCFL (Cold Cathode Fluorescent Lamp) technology, typically rated for 50,000 to 60,000 hours.

* Interface: Features a 30-pin LVDS (1 ch, 8-bit) connection Twscreen Beyondinfinite.

Market Trends & Availability (2026)

* Production Status: The entire T315XW02 line is End of Life (EOL). AUO has long since transitioned to LED-backlit panels (e.g., T315XW03, T315XW06) Twscreen Alibaba.

* Supply Chain: Current inventory consists almost exclusively of "New Old Stock" (NOS) or refurbished units. High-quality "Grade A" original stock is becoming increasingly rare and is mostly sourced for specialized industrial repair or legacy TV maintenance Alibaba.

* Pricing Insights: On B2B platforms like Alibaba, prices fluctuate significantly based on condition and specific sub-model:

* Low End: ~$10 for basic units, though these often require high MOQs or may be used Alibaba.

* High End: ~$100 to $286 for "Original in Stock" or specialized versions like T315XW02 VS Alibaba Alibaba.

Common Repair & Maintenance Issues

Technicians often encounter specific failures with this legacy panel Badcaps Youtube:

* T-Con Board Failures: Symptoms include a white screen, vertical bars, or "bad color gamma" Badcaps.

* CCFL Aging: Flickering or a dim display caused by the backlight lamps reaching the end of their lifecycle.

* Tab Bonding Issues: Vertical lines often indicate failure in the COF (Chip on Film) or tab bonds, which are generally difficult to repair without specialized bonding machines Allpcb.

I have compiled a list of currently available T315XW02 variants and their wholesale pricing from B2B platforms for your reference.

Here is the analysis for the T315XW02 LCD market. You can continue with:
