Posted by u/[Deleted Account] - 2 votes and 12 comments Again, just check the manuals of your devices, there should be a section describing the connectors and pin assignments used ... Iirc mini XLR is 3 pin. TA4F is 4 pins ... While I'll explicitly say TA4 / TA5 if I'm meaning one of the other kinds. ... All the TAs are mini XLRs. A TA4F is a mini XLR4F ... If someone just says mini xlr, they mean TA3. Those are interchangeable. But if it's more specific, they could be referring to more pins. They make a 3-socket version (TA3F) as well as 4-socket (TA4F) and maybe even 5-socket (TA5F?) for different applications. The TA4F is popular on wireless bodypack transmitters because it allows for two different audio inputs, like a lavalier or headworn mic with one impedance and an electric guitar input which needs a different impedance. The mics use one pin for audio, while the guitar cable uses a different pin. And you still have one pin for DC voltage and one for ground. ... Generally, the TA connectors are often called mini-XLR as they are very similar (except the size). In my shop we say TA3 or TA5 or whatever, and reserve the term XLR for the connectors originally named as such. [Question] I need an adapter for a Shure ta4 mic to an XLR input on my recorder. ... I bought a lav mic with TA4F ("mini XLR") female connector by mistake.

Mini XLR Connector: Pinout, Wiring & 5 Key Uses

verchilconnect.com

Because the 3-pin version carries a balanced signal, it follows the same physics as a standard XLR cable — you can run 50–100 ft (15–30 m) without significant interference. Although the technical limit is generous, mini XLR cables are usually used for short connections (within 2 m), such as a lavalier to a bodypack. TA3F is a 3-pin mini XLR; TA4F is a 4-pin mini XLR — and they are not interchangeable. The mini XLR connector — technically known as the Tiny QG (TQG) or TA series (such as TA3F and TA4F) — is a scaled-down version of the standard XLR connector. A mini XLR connector (also called TA3F, TA4F, or Tiny QG) is a miniaturized 3-to-5-pin version of the standard XLR, about 10 mm in diameter. It carries balanced audio in space-constrained gear like wireless bodypack transmitters, cinema cameras, and detachable headphone cables. For the standard XLR pinout reference, see our XLR connector pinout guide. The 4-pin TA4 is common in Shure, AKG, and Sennheiser-compatible wireless systems. A typical Shure wiring: ... ⚠️ CRITICAL — TA4 has NO universal standard. Because each manufacturer wires the TA4 differently, a Shure headset mic will NOT work on an AKG or Sennheiser bodypack without a rewired adapter. Before swapping mics between systems, consult the manufacturer’s pinout (e.g., Shure’s official TA4M/TA4F knowledge base) — because mixing incompatible TA4 wiring can damage the capsule or transmitter, never assume cross-brand compatibility.
