Tb Drive Pins

What Do The Jumper Pins On The Back Of Your Hard Drive Do?

www.howtogeek.com

These pins are called jumpers, and are used to enable specific types of settings. They're not used so much with modern hard drives, except in some special circumstances. If you're under a certain age, or you just haven't been into computer hardware for long, you've probably never heard of hard drive jumpers. You enable particular settings by placing a jumper shunt onto specific pins---creating an electrical circuit between them. The settings these jumpers enable are hard-coded onto a drive's programmed printed circuit board. So what do jumpers do? Well, not so much anymore. Back before SATA became the standard interface for drives, computers used the Integrated Drive Electronics (IDE) standard. So why are the jumper pins still around? Well, most drives don't have them at all. On those that do, they enable a few specialized settings. Exactly what the pins do depends on your drive and its manufacturer. For example, Western Digital's full-sized SATA hard drives let you use jumpers to set the following parameters: You'll find the relevant support site that tells you which ones to use. Unless you have need of those specialty settings, you can safely ignore the jumper pins on your drive. It will work fine without them on pretty much any computer made in the last ten years. Most of the options above are included for the sake of backwards compatibility.

hard drive - What is the purpose of this 4-pin interface on SATA ...

superuser.com

I have 4 HDDs here with me, from 3 different manufacturers, and all of them have the following 4-pin extra interface beside the SATA connector: ... On old IDE devices, there was a similar interface used to select operational mode (master/slave), but on SATA it doesn't make sense anymore. Could someone tell me what this interface is intended to do and why it doesn't exist on SSDs? It is used in any practical situations? ... Those are jumper settings, similar to the IDE drives you mention, but for SATA specific options depending on the drive maker. For example, on this Western Digital support page for mobile drives, it shows two options: Reduced Power Spinup - RPS: Used by external hard disks to reduce spinup current and allows it to work over USB interface. Spread Spectrum Clocking - SSC: Used when your SATA controller doesn't support SSC by default. Also, it doesn't exists on SSDs because there is no spinup or spread spectrum related to solid-state devices. @Adrian Cox mentions in the comments below, a different pin function for Seagate drives. I wouldn't be surprised if the drive ran at a slower RPM as well. ... @kayEss As USB ports are designed to work with 500mA max, if you start a HDD with 1A it will burn... ... You should probably emphasise that the jumpers are manufacturer specific. For instance, Seagate have the same four pin connector, but with a different function: knowledge.seagate.com/articles/en_US/FAQ/193991en Which one is responsible for producing an induced current: the change in magnetic field or the induced electric field?

r/homelab on Reddit: What are the pins visible on the external ...

www.reddit.com

Posted by u/TheExtremeDetailer - 100 votes and 45 comments I was naive and thought all external drives were swappable and thought I was going to easily shuck my external drives for a ZFS pool later down the line. Now obviously this is not sata but a Micro-B plug directly soldered onto the board. But I wonder, what stops me from making an internal connector or can I even do one? What are those pins? ... The pins are likely diagnostic connectors. The drive is made to be used with that USB connector, and there isn't a way to convert it to SATA. You can shuck the Seasgate ones. they use internal drives... ... Those are diagnostic pins. They are used internally to perform certain tests, and may be used by some enclosures to provide extraneous features. As for converting to SATA, afraid you are plumb out of luck. The only shuckable 2,5" drives are Seagate and Maxtor ... And here I thought they were pins for the old master/slave configuration stuff.

r/techsupport on Reddit: What are the pins next to the SATA ...

www.reddit.com

Posted by u/imstressedman - 5 votes and 7 comments I pulled out two old HDD of my computer and I'm curious to know what these pins are used for. The 7200 RPM HDD has 8 pins and the 5400 RPM HDD has only 2 pins. ... Thank you! Didn't know about this. ... I actually only knew the bare minimum about them until a few minutes ago — interesting to read about :) ... On SATA drives the pins are probably for enabling/disabling features like spread spectrum (the frequency of data transfers was varied to make radio interference less bothersome), limiting the speed of transfers (to 150 Mbytes/sec, because some of the earliest SATA controllers were incompatible with faster drives), limiting the amount of current drawn by the motor when power was applied (needed by some old laptops), and for communicating with the drive for diagnostics & repairs in "terminal mode", the latter explained here: http://www.hddoracle.com/viewtopic.php?f=22&t=217 Interesting how your drives have 2 and 8 cuz my Seagate 1000 Gbytes drive has 4 pins. ... Depends on the drive. Usually there was a diagram on the model sticker that showed what they did. Often it was for using the drives with older computers that couldn't understand/show the full capacity. Can’t seem to figure out this hard drive’s connection type. ... Sega Star Wars Trilogy Arcade: Are ROM chips missing from both of these boards? Is it normal for these spots to be empty? ... What is this port on my hdd. The 8 pin one. Not sure if that's another ports to its right.

What's the purpose of the pins besides th… - Apple Community

discussions.apple.com

They carried both electrical power and data input/output throughput for the drive. I used to deal with these all the time when working/upgrading different types of tower Macs, I've seen these is G3, G4 and G5 PowerMacs and early Intel Mac Pros. These connector pins carry both power AND data throughput. I always called these SATA connectors. ... I thought master/slave wasn't used any more... ... Actually, looking closer at those pins, those look like the pins for the older SATA connectors. THAT'S WHAT THOSE REALLY ARE! If those pins are what I think they are those pins setup a drive as "master" or "slave" drive when a computer has/uses more than one hard drive. Apple uses these pins for connecting up the temp sensor in Macs, since iMacs only have one installed hard drive. ... Older computers used these to connect up hard drives and optical drives. Those are the pins for older SATA drive connectors. ... I can see those pins in newer drives too. I don't know what the term for these pins is, GPIO (general purpose input output)? ... that's the data connector, the wider is the power connector. I'm talking about the other little pins on the side. ... Edited above. This is the cable. It's a Molex connection. The Molex connection is what carried the power to the drive from the computer"s power supply.

Anatomy of a Storage Drive: Hard Disk Drives | TechSpot

www.techspot.com

Even tiny 1.8" HDDs use metal for the body, although they tend to be made from aluminum, rather than steel, as they're designed to be as light as possible. Flipping the drive over, we can see a circuit board and a bunch of connections. The one at the top of the board is for the motor that spins the disks, whereas the bottom three are, from left to right, jumper pins to allow the drive to be configured for certain setups, SATA (Serial ATA) data, and SATA power. The specification of the format has gone through lots of revisions since then and we're currently on version 3.5. Our hard drive cadaver, though, is an older version but this only affects a single pin in the power connection. The data connections use what is called differential signalling to send and receive data: the A+ and A- pins are used to transmit instructions and data to the hard drive, whereas the B pins are used to receive those signals. On the power side of things, you can see that there are essentially two of every voltage (+3.3, +5, and +12V); most aren't used, though, as HDDs don't need a lot of power. This particular Seagate model uses around 8 – 9 watts under heavy load and 5 – 6 watts when idle. The power pins labelled with PC are pre-charge ones: it allows the hard drive to be pulled in and out, while the computer is still on (a.k.a. For today's article, we're going to take apart something that's not quite that size, but still relatively modern: a 3.5" Seagate Barracuda 3 TB HDD, specifically the ST3000DM001 model, infamous for its high failure rate and subsequent lawsuits. This one is dead, too, so in truth this is more of an autopsy, rather than an anatomy lesson. The bulk of the hard drive is cast metal. The forces inside the device, when under heavy usage, can be pretty serious, so the use of thick metal stops the body from flexing and vibrating.
