ZIF tape connections are used for connecting Parallel ATA and Serial ATA disk drives (mostly drives in the 1.8-inch form factor). PATA hard drives with ZIF-style connectors were used primarily in the design of ultra-portable notebooks. They have since been phased out, as SATA has a relatively small-form-factor connector by default. ZIF sockets can be used for ball grid array chips, particularly during development. These sockets tend to be unreliable, failing to grab all the solder balls. Another type of BGA socket, also free of insertion force but not a "ZIF socket" in the traditional sense, does a better job by using spring pins to push up underneath the balls. Zero insertion force (ZIF) is a type of IC socket or electrical connector that requires very little (but not literally zero) force for insertion. With a ZIF socket, before the IC is inserted, a lever or slider on the side of the socket is moved, pushing all the sprung contacts apart so that ... With a ZIF socket, before the IC is inserted, a lever or slider on the side of the socket is moved, pushing all the sprung contacts apart so that the IC can be inserted with very little force - generally the weight of the IC itself is sufficient and no external downward force is required. The lever is then moved back, allowing the contacts to close and grip the pins of the IC. ZIF sockets are much more expensive than standard IC sockets and also tend to take up a larger board area due to the space taken up by the lever mechanism.
