Zx95 2536c

The phrase 'zx95 2536c' refers to the Mini-Circuits ZX95-2536C-S+, a high-performance Coaxial Voltage Controlled Oscillator (VCO) designed for the 2315 to 2536 MHz frequency range MinicircuitsMinicircuits. It is a critical component in RF and microwave engineering, particularly for signal generation and local oscillator (LO) injection Alibaba.

Technical Profile

• Frequency Range: 2315–2536 MHz, covering key bands for WiMAX, LTE Band 7, and TD-SCDMA AlibabaMinicircuits.
• Key Specs: Low phase noise (−105 dBc/Hz @ 100 kHz offset), +5 dBm typical output power, and linear tuning (typically 38 MHz/V) Minicircuits.
• Interface: Robust coaxial design with SMA connectors, optimized for lab-grade testing and rapid prototyping AlibabaMinicircuits.

Market Trends & Insights

• "Plug-and-Play" Shift: Engineers are increasingly choosing coaxial modules like the ZX95 over discrete IC-based VCOs to save development time. While the unit cost is higher ($135–$165), it eliminates complex PCB layout and tuning risks Alibaba.
• SDR & 5G Momentum: There is a surge in demand driven by Software Defined Radio (SDR) platforms (e.g., USRP, LimeSDR) and testing requirements for 5G NR FR1 bands that overlap the 2.3–2.5 GHz spectrum Alibaba.
• Market Transition: For high-volume consumer manufacturing (>5,000 units), the market typically shifts from these modular components toward integrated VCO/PLL ICs to optimize cost Alibaba.

Sourcing Insights

I have identified 12 relevant product listings and 30 verified suppliers primarily located in Shenzhen, China, specializing in these high-precision RF components. Prices for single units in the secondary market can vary significantly from $147 to over $300 EbayAlibaba.

Detailed sourcing options and technical comparisons are provided in the deliverable below.
