Sh69p24m Ic

The SH69P24M is a 4-bit single-chip micro-controller based on the SH6610D architecture, primarily manufactured by Sino Wealth (Sinowealth Electronics). It is a specialized integrated circuit (IC) widely used in consumer appliances, particularly induction cooktops and household electronics requiring integrated LCD/LED drivers. SeekicIc-Components

Technical Specifications

* Architecture: 4-bit RISC micro-controller with integrated display driving circuitry. SeekicAlldatasheet

* Memory: Features 4K x 16 bits of One-Time Programmable (OTP) ROM and 322 x 4 bits of RAM (including dedicated LCD RAM). SeekicAlldatasheet

* Display Support: Built-in driver capable of supporting both LCD and LED displays, with specific high-current drive ports for LED numeric segments. SeekicDatasheet

* Peripherals: Includes two 8-bit auto-reload timers, a 16-bit pulse measurement timer, a 2-channel tone generator, and a watchdog timer for system reliability. DatasheetAlldatasheet

* Operating Range: Supports a voltage range of 2.4V to 5.5V, making it suitable for standard battery-powered or mains-connected appliances. Alldatasheet

Market Trends & Insights (2025–2026)

* Legacy Dominance: Despite the rise of 8-bit and 32-bit controllers, the SH69P24M remains a "staple" in the Asian appliance market due to its low cost and proven performance in induction cookers and digital clocks. IndiamartIc-Components

* Pricing: Current market prices vary by region and volume. In retail/repair markets like New Delhi, it is priced around ₹160 (~$1.92 USD) per piece, while bulk wholesale prices from Hong Kong distributors range between $0.58 and $0.64 USD per unit for 100+ pieces. SeekicIndiamart

* Availability: While major Western distributors (like DigiKey) do not stock it, availability is robust on B2B platforms such as Alibaba.com, IndiaMART, and SeekIC. Most stock is currently concentrated in Hong Kong and Shenzhen, China. DigipartWorldwayelecAlibaba

* Demand Drivers: The primary demand is driven by the repair market and low-cost manufacturing in emerging markets where simple, cost-efficient display control is prioritized over high processing power. RootsanalysisUtmel

Supplier Overview

Verified suppliers actively listing this specific model include:

* NELCOM INTERNATIONAL LIMITED (HK): A specialized IC distributor with confirmed SH69P24M stock.
